MODEL |
12" |
18" |
24"
& 26" |
30" |
32" |
36" |
42" |
48" |
|
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
CAPACITY |
Length of Ram- stroke |
305 |
457 |
660 |
762 |
815 |
915 |
1070 |
1215 |
Length of Ram |
660 |
914 |
1325 |
1400 |
1536 |
1640 |
2135 |
2285 |
Length x Width of ram Bearing |
660 x 178 |
711 x 245 |
995 x 280 |
995 x 280 |
1145 x 300 |
1145 x 300 |
1600 x 405 |
1650 x 430 |
Max/Min distance of Table from
Ram |
257/41 |
406/89 |
485/109 |
485/109 |
521/140 |
521/140 |
521/140 |
521/140 |
Table |
Working Surface of Table |
300 x 228 |
381 x 279 |
610 x 330 |
762 x 370 |
810 x 387 |
915 x 387 |
1050 x 562 |
1200 x 570 |
Max. Horizontal Table Travel |
419 |
457 |
665 |
670 |
762 |
865 |
1070 |
1215 |
Max. Vertical Table Travel |
140 |
305 |
432 |
435 |
381 |
381 |
457 |
460 |
Angular Movement of Table |
60 deg. |
60 deg. |
60 deg. |
60 deg. |
FIx |
FIx |
FIx |
FIx |
Tool Head |
Max. Tool Shank Size |
16 x 22 |
30 x 16 |
38 x 21 |
38 x 21 |
38 x 21 |
38 x 21 |
38 x 25 |
40 x 27 |
Max. Vertical travel of Tool Slide |
140 |
152 |
152 |
152 |
152 |
228 |
305 |
330 |
Max. Swivel of Tool Head |
60 deg. |
60 deg. |
60 deg. |
60 deg. |
60 deg. |
60 deg. |
60 deg. |
60 deg. |
Speed & Feeds |
|
|
|
|
|
|
|
|
Diameter of Clutch Pulley |
235 |
311 |
311 |
311 |
405 |
405 |
405 |
405 |
Number of Ram Speeds/Strokes |
3 |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
Range of Ram Strokes Per Minute |
30 to 90 |
17 to 75 |
12 to 72 |
12 to 72 |
12 to 67 |
12 to 67 |
10 to 60 |
10 to 60 |
Diameter of Motor Pulley |
76 |
89 |
89 |
89 |
100 |
100 |
100 |
100 |
Range of Table Feeds/Stroke |
0.22-0.88 |
0.22-0.88 |
0.22-0.88 |
0.22-0.88 |
0.22-0.88 |
0.22-0.88 |
0.22-0.88 |
0.22-0.88 |
Tool Head Feed |
Hand Feed |
Hand Feed |
Hand Feed |
Hand Feed |
Hand Feed |
Hand Feed |
Hand Feed |
Hand Feed |
Electric
Equipments |
Main Motor Drive 960 RPm |
1.5 H.P. |
2 H.P. |
3 H.P. |
3 H.P. |
5 H.P. |
5 H.P. |
7.5 H.P. |
7.5 H.P. |
V-Belt Section |
B-35 |
B-55 |
B-60 |
B-60 |
B-72 |
B-72 |
B-85 |
B-92 |
Motor Starter |
3.5 AMP |
3.5 AMP |
5 AMP |
5 AMP |
15 AMP |
15 AMP |
15 AMP |
15 AMP |
Overall
Dimensions |
Length |
1290 |
1580 |
1980 |
2080 |
2100 |
220 |
2400 |
2600 |
Width |
838 |
948 |
1067 |
1117 |
1500 |
1650 |
1900 |
2100 |
Height |
1371 |
1400 |
1600 |
1650 |
1900 |
2000 |
2150 |
2350 |
Weight (Approx.) |
600 Kg. |
1250 Kg. |
1750 Kg. |
2000 Kg. |
3250 Kg. |
3750 Kg. |
4500 Kg. |
5500 Kg. |
